Description

– *Inverter Mode*:
– Rated power: 5500VA / 5500W.
– DC input: 48 VDC, 131 A.
– AC output: 230 VAC, 50/60 Hz, 23.9 A, single phase (1φ).

– *AC Charger Mode*:
– AC input: 230 VAC, 50/60 Hz, 40 A, 1φ.
– DC output: 54 VDC.
– Max charge current: 100 A (default 60 A).
– AC output: 230 VAC, 50/60 Hz, 23.9 A, 1φ.

– *Solar Charger Mode*:
– Rated power: 6000 W.
– Max charger current: 120 A.
– Max PV input current: 18 A.
– Max solar voltage (VOC): 500 VDC.
– MPPT voltage range: 60 ~ 500 VDC.

– *General*:
– Ingress protection: IP21.
– Protective class: Class I.
– Operating temperature: 0 °C to 55 °C.
– Compliance: CE, RoHS.
